2.0mm HDPE Heat Shrink Wrap Tape with Enhanced UV Resistance
| Place of Origin | CHINA |
|---|---|
| Brand Name | Forever |
| Certification | COO,SGS REPORT, ISO MANAGER SYSTEM CERTIFICATES |
| Model Number | HT60, HT 80, HT 120 |
| Minimum Order Quantity | 100 SETS |
| Packaging Details | different pipe diameter with different packing for each box |
| Delivery Time | 7-14 days |
| Payment Terms | T/T |
| Supply Ability | 1000 sets per day |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Uv Resistance | Good | Color | Black |
|---|---|---|---|
| Length | Small Pieces Or Jumbo Roll Is Ok | Elongation At Break | More Than 500% |
| Thickness | 1.8mm, 2.0mm, 2, 2mm, 2.3mm, 2.5mm, 2.7mm, 3.0mm, 3.2 Mm | Compatible Line Coating | PE/FBE/Coal Tar/DFBE |
| Materials | HDPE | Product Form | Pieces Or Rolls |
Product Description
Product Description:
Heat-shrinkable materials are composed of an outer layer made of cross-linked polyolefin, as well as an inner adhesive made of thermoplastic materials material. The backing shrinks in response to heat, inducing circumferential compression that enhances the bonding of the sleeve to the surface of the pipe joints.
As a filed-joint coating system, heat-shrinkable sleeves represent one of the most robust coating systems accessible. This coating system is typically made up of a solvent-free, high-performance epoxy, adhesive copolymer, and modified cross-linked polyethylene, and it is designed to match the structure of mil-applied three-layer PE coatings while also meeting their performance standards. The coatings are versatile in that they are compatible with all commonly used pipe coatings, including polyethylene, coal tar enamel, and fusion-bonded epoxy.
| Property | Test temp. | Unit |
HST 60 Tmax 65 °C |
HST 80 Tmax 85 °C |
Test method |
| Tensile Strength | 23 °C | MPA | ≥23 | ≥23 | ASTM D-638 |
| Elongation at Break | 23 °C | % | ≥500 | ≥500 | ASTM D-638 |
| Hardness, Shore D | 23 °C | D | ≥52 | ≥52 | ASTM D-2240 |
| Dielectric Strength | 23 °C | Kv/mm | ≥32 | ≥32 | ASTM D-149 |
| Water Absorption | 23 °C | % | ≤0.1 | ≤0.1 | ASTM D-570 |
| Volume Resistivity | 23 °C | ohm.cm | ≥1.0X1018 | ≥1.0X1018 | ASTM D-257 |
| Thickness | — | mm | ≥2.0 | ≥2.0 | ISO 21809-3 Annex B |
| Width | - | mm | 100 mm to 800 mm | ASTM D 1000 | |
| Ring ball Softening Point for Adhesive | 23 °C | °C | ≥90 | ≥121 | ASTM E-28 |
| Holiday detection at 5 KV/ mm + 5 KV | — | — | No holiday | No holiday | ISO 21809-3 Annex C |
| Impact resistance (holiday detection at 5 KV/mm + 5 KV) | 23 °C | J/mm | ≥5 | ≥7 | ISO 21809-3 Annex D |
|
Indentation resistance: Pres- sure and residual thickness |
23 °C | N/mm2 | ≥1.0 | ≥10.0 |
ISO 21809-3 Annex E |
| mm | ≥0.60 | ≥1.0 | |||
| Tmax | N/mm2 | ≥1,0 | ≥1,0 | ||
| mm | ≥0,60 | ≥1,0 | |||
| Cathodic disbondment at 28 days | 23 °C | mm | ≤10 | ≤15 | ISO 21809-3 Annex G |
| Tmax | mm | ≤20 | ≤20 | — | |
| Peel strength to pipe surface and plant applied coating | 23 °C | N/mm | ≥1.0 | ≥3.0 | ISO 21809-3 Annex H |
| Tmax | N/mm | ≥0.10 | ≥0.20 | ISO 21809-3 Annex H | |
| Peel strength to pipe surface and plant applied coating after 100-day hot-water immersion test at Tmax limited |
23 °C |
P100/P0 |
≥0.75 |
≥0.75 |
|
| Lap shear strength at 10 mm/ min | 23 °C | N/mm2 | ≥0.10 | ≥5.0 | ISO 21809-3 Annex J |
| Tmax | N/mm2 | ≥0.01 | ≥0.10 | ||
| Thermal ageing resistance (aged at Tmax + 20 °C) |
ISO 21809-3 Annex M |
||||
|
Elongation at break E100/E0 E100/E70 |
≥0.75 ≥0.80 |
≥0.75 ≥0.80 |
|||
|
Peel strength to pipe surface P100/P0 P100/P70 |
23 °C |
- |
≥0.75 ≥0.80 |
≥0.75 ≥0.80 |
|
Features:
Incredible multifunctional adhesive is now available for your installation needs. This amazing adhesive allows for lower installation in pre-heat temperature and bonding to 3LPE/DFBE/FBE/CTE.
You can trust this adhesive to resist shear forces caused by soil and thermal movements, making it perfect for long-term installations.
Not only that, it also offers superior cathodic disbondment, hot water immersion resistance, and thermal ageing resistance. This gives optimum barrier long term protection against corrosion.
By using this adhesive, you can significantly reduce time and costs by lowering pre-heat temperature and using wet epoxy primer application. This is perfect for those who want to save time and money without sacrificing quality.
Applications:
Instructions for Use
To ensure the best results, please follow the steps below carefully:
Mixing the Epoxy Primer
Mix the two components of epoxy primer thoroughly before application. It is important to ensure a thorough mixing to guarantee optimal adhesion.
Applying the Epoxy Primer
Apply the epoxy primer to a minimum thickness of 150 µm and covering at least.10 mm of the adjacent coating. Avoid mixing more primer than can be applied during the pot life.
Applying the Sleeve
While the epoxy is still wet, apply the sleeve. The adhesive should be heated before application. Once the sleeve is wrapped, the closure patch must be heated and applied. The whole sleeve should be heat-shrunk to fit tightly around the joint.
Post-Heating
After application, post heating should be used to soften the sleeve and allow the removal of any trapped air.
Customization:
Our large heat shrink sleeve comes from CHINA and has a minimum order quantity of 100 sets, with packaging details varying for each box depending on the pipe diameter. The delivery time takes 7-14 days, and payment terms are T/T. Our supply ability for this product is 1000 sets per day.
For customized product form and heat shrinkage coatings, kindly contact our customer service team for more information.
