Liquid epoxy primer solvent-free two component Part A and Part B
| Place of Origin | Sichuan,CHina |
|---|---|
| Brand Name | Forever |
| Certification | Third party test report and ISO certificates |
| Model Number | Part A and Part B |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | drum + carton + pallet |
| Delivery Time | 14 days |
| Payment Terms | L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability | 500 sets /day |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Description | High Performance Liquid Epoxy Coatings | Designed For | Corrosion Protection Of Buried Pipelines, |
|---|---|---|---|
| Operating At Temperatures | Up To 120 ℃ | Usage | Used For New Construction, Including Girth Welds, Bends, Fittings Etc |
| Density | Part B 1.0 Kg/L |
Product Description
Product Profile
Two-part solvent-free liquid epoxy coating is coated on the surface of metal pipe before installing heat-shrinkable sleeves (tubes). The epoxy coating is solvent-free and can cure at room temperature. After curing, the coating surface is flat and smooth. The products are contained in the metallic can and bear operation tools.
Technical data sheet
| Item | Unit | Technical requirements |
| Thickness | μm | ≥150 |
| Adhesive Fore | Grade | ≤2 |
| 48h cathode peel | mm | ≤10 |
| Impact Strength(1.5J, -30℃) | No pinhole | |
| Impact strength (room temperature) | J | ≥8 |
| Bend Resistance | 1o | No cracks |
| Bulk electric resistivity | Ω.m | ≥1.0×1011 |
| Dielectric strength | MV/m | ≥30 |
Part A :
| NO. | Item |
Unit
|
Requirement
|
Test result
|
| 1 |
Specific Gravity @ 23℃-A
|
Kg/L | 1.7±0.03 | 1.70 |
| 2 | Solid Content | % | ≥ 95 | ≥ 95 |
| 3 | Lap Shear Strength | MPA | ≥ 10 | 15 |
| 4 |
Adhesion 23±2℃ 60±2℃ |
MPA |
≥ 10 ≥ 7 |
12 9 |
| 5 |
Cathodic Disbonding 65℃ 48h 65℃ 30d |
mm |
≤6 ≤10 |
2.2 7.5 |
